Carbon Molecular Sieve(CMS-260)
Model： CMS-260
Uses: pressure swing adsorption (PSA) nitrogen production
Shape: Ф 1.0-1.3mm or customized, black columnar
Composition: Carbon
Characteristic:
Index:
Package:
Application area:
Product Details
1) Product Overview
Name: Carbon Molecular Sieve
Model: CMS-260
Size: Φ1.0-1.3mm or customized
Bulk density: 640 - 680kg/m3
Adsorption cycle: 2 ×40s
Crush strength: ≥65N/piece
Package: 20/40/137kg plastic drum
Inlet temperature: 20~30℃
Application: used for nitrogen generators to separate O2 and N2 in the air.
2) Specifications of Carbon Molecular Sieve
Model No. | Adsorbent pressure (Mpa) | N2 purity (%) | N2 production rate (Nm3/h.t) | Air/N2 |
CMS-260 | 0.7 | 96 | 580 | 1.8 |
97 | 520 | 1.92 | ||
98 | 475 | 2 | ||
99 | 382 | 2.15 | ||
99.5 | 315 | 2.53 | ||
99.9 | 230 | 3.14 | ||
99.99 | 150 | 4.34 | ||
99.999 | 90 | 5.65 |
CMS-260 features high yield, high purity and stability, and is suitable for use in most industrial nitrogen (such as medicine, Chemical engineering, metal heat treatment, etc)
3) Features of Carbon Molecular Sieve
- Low Dust
- Large and Fast N2 Production
- High N2 Recovery Rate
- High Cycle Life
4) Packaging
20kg/40kg/ 137kg palstic drum
